Uncompromising Security, Day or Night, Rain or Shine
See it all, hear it all. Lorex A4 cameras offer crystal-clear video, audio recording, smart motion detection, and IP67 weatherproof ratings for complete security.
Resolution
Color Night
Vision
IP67
Weatherproof
Built-in
Microphone
Person and Vehicle
Detection
Sharp Details, Sharp Security
2K resolution captures detailed footage for undeniable evidence.
Night Vision Evolved: Capture Every Detail in Color
Don’t miss a thing with Lorex’s Color Night Vision (CNV) in low light conditions or crisp black and white footage in total darkness.
All-Season Security
Heavy-duty aluminum exteriors and IP67 weatherproof rated designs guarantee extreme temperature (-40°F to +140°) and weather durability.
Hear the Whole Story
A built-in microphone captures audio for an extra layer of evidence.
Smart Motion Detection (Person and Vehicle)
Person and vehicle detection helps identify and categorize motion events, and limit unnecessary alerts caused by other moving objects.
Wired Reliability
Connect A4 cameras to a compatible NVR for a stable camera connection, 24/7 continuous recording and the ability to record without internet.
Product Specifications
| Capteur d'image | CMOS 4MP |
| Format vidéo | NTSC |
| Compression vidéo | H.265/H264 (flux principal et sous-flux) |
| Flux vidéo | 2 (courant principal et sous-courant) |
| Angle de vue (diagonale) | 114° |
| Lentille/Type de lentille | 2,8 mm F1.6/Fixe |
| Résolution/Fréquence d'images | 4 Mpx (2688 × 1520/2560 × 1440) ; 3MP (2304 × 1296); 1080p (1920 × 1080) ; 1,3 M (1280 × 960) ; 720p (1280 × 720) ; D1 (704 × 576/704 × 480); VGA (640 × 480) ; CIF (352 × 288/352 × 240) |
| Fréquence d'images (maximale) | Grand public: 2688 × 1520 à (1–20 ips) 2560 × 1440 à (1–25/30 ips) Sous-flux : 704 × 576 à (1–25 ips) 704 × 480 à (1–30 ips) |
| WDR | Oui |
| Terminaison | RJ45 |
| Rapport hauteur/largeur | 16:9 |
| Microphone | Oui |
| Sirène | Non |
| Conversation bidirectionnelle | Non |
| Portée de vision nocturne | 98 pieds (30 m) |
| Vision nocturne couleur | Oui |
| Détection de mouvement intelligente | Oui |
| Types de détection | Véhicule et personne |
| Matériau du boîtier de l'appareil photo | Alliage d'aluminium |
| Exigences d'alimentation | PoE (Power over Ethernet Classe 802.3af) / 12 V CC |
| Consommation électrique (max) | 5,1 W (POE) et 4,2 W (DC12 V) |
| Dimensions de la caméra (L x P x H) | 6,5 x 2,7 x 2,7 po 166,2 x 70 x 70 mm |
| Poids de l'appareil photo | 1,06 lb / 0,48 kg |
| Température de fonctionnement | -40 °F (-40 °C) ~ +60 °C (+140 °F) |
| Humidité | ≤95% |
| Évaluation environnementale | IP67 |
| Certification | FCC, CE |
What's Included?
- Ethernet Connector
- 12V DC Power Connector
- Cable Notch
- Adjustment Screw
- Adjustment Knob
- Reset Button
- MicroSD Card Slot*
- Sun Shield & Adjustment Screw
- Microphone
- Camera Lens
- IR (Infrared) Light
Package Contents:
4MP IP PoE Wired Bullet Camera
Mounting Kit
Weather-resistant Cap
*A microSD card can be inserted for independent recording. Data can be accessed through the camera using a web browser but will not upload to the NVR or to the cloud for mobile app viewing
