Protect your camera cables from harsh weather, dust, and vandalism, while keeping your camera area neat and tidy with the Lorex junction box. Quickly and easily access the camera cables and connectors when needed without having to remove the camera. With the added cable protection, this junction box will help preserve your cameras for years to come.
Get the optimal view
Enjoy the flexibility the Junction Box offers, allowing you to avoid obstructions such as a low eavestrough or a dropped fascia. Simply lower your camera with the junction box and enjoy an optimal viewing angle.
Added Protection
Junction boxes can hide and protect power supplies and connecting components, making it more challenging for intruders to damage with or disable the camera. With the durable Weather-Resistant IP66 Rating, the metal exterior ensures that you have maximum protection from harsh weather and elements.
Organize your space
Ensure that your camera area is tidy and prevent cable tangling with the Junction Box. This makes it easier to troubleshoot or replace components if necessary. Use with a Conduit to hide cabling from running across walls and ceilings.
Enjoy flexible installation
With multiple different mounting options, the Junction box offers diverse camera placement options for ceiling, wall or counter.
Product Specifications
| Material | Aluminium |
|---|---|
| Finishing | Powder Spray |
| Color | White, Black |
| Load-Bearing Weight | 6.61 lbs / 3 kg |
| Operating Temperature | -40 °F to 140 °F / -40 °C to 60 °C |
| Humidity | <90% RH |
|---|---|
| Ingress Protection | IP66 |
| Product Weight | 1.2 lb / 0.54 kg |
| Product Dimensions (W × D × H) | 5.27 × 5.25 × 2.05" / 134 × 133.5 × 52 mm |
What's Included?
Package Contents:
Junction Box
(× 1)
Mounting Screw
(× 4)
Mounting Anchor
(× 4)
Allen Key
(× 1)
Machine Screw
(× 3)
Washer
(× 4)
Cable Gland
(× 1)
Product Compatibility
Product Support
AJLD-1B2, AJLD-1W2 Series - Outdoor Junction Box with Cable Gland for Dome and Turret Cameras
